Ailes arrière – Stabilité et équilibre en navigation
L’aile arrière influence la stabilité, la réactivité en courbe et le comportement à haute vitesse. En fonction de sa forme et de sa taille, elle permet d’affiner votre configuration pour obtenir le bon équilibre selon votre style de glisse.
CABRINHA H-Series Rear Stabilizer
187,00 €*
FUSION H TAIL STABILISER
HIGH ASPECT FOIL
HS180
DESIGN PROFILE
Swept outline, Ultra lean efficient profile, moderate anhedral
RIDER PROFIL
Versatile efficient and fast wing set for high performance
WING FEATURES
Optimal efficiency & maneuverability
Flat center, to downward tips, for pefect balance between locked-in feel and agility
Single molded components for minimal drag
Full prepreg carbon construction
PMI core for supperior strength to weight ratio
Includes: Stabilizer, wing covers, 2pcs m6 ss316 torx Ti coated screws
The HS180 High aspect stabiliser has been seamlessly molded as one single component into the fuselage to give exceptional efficiency and stiffness. it allows the rider complete control through varying degrees of the turn and has been precisely tuned for use with all H-series and X-series wings.
NORTH Sonar S178 Stabilizer Back Wing 2023
179,00 €*
Flat, loose and even faster, the new S178 Stabilizer is a high-speed upgrade to the Sonar Foil System for experienced riders. We recommend pairing the S178 with Front Wing size HA950, or smaller. The S178 has a higher aspect ratio than the S208.
Features
Top mounted for early breach recovery
Carbon pre-preg construction
Thin profile section for reduced drag
Materials
Pre-Preg Carbon
NORTH Sonar S208 Stabilizer 2022
189,00 €*
Flat, loose and fast, the new S208 Stabilizer is another high performance upgrade to the Sonar Foil System for experienced riders. The S208 has a higher aspect ratio than the S210, which means less drag, and the flatter rondure (front view) enables more manoeuvrability. As we’ve increased our front wing range, we’ve needed to match the lift force of the front wing with the stabilizer. While your front wing creates vertical lift, your stabilizer has a downward acting force, which prevents the front wing from nose-diving. A larger stabilizer translates into more front foot pressure, while a smaller stabilizer equals less front foot pressure. The North stabs are mounted on top of the fuselage, which helps them to avoid turbulence from the flow of the front wing, creating a smoother ride. This top mounting also gives the rider an early breach warning - the stab pierces the water surface first, giving you a better chance of recovery before your front wing gets too high. Like the Front Wings, all Sonar Stabilizers are pre-preg carbon construction, ensuring optimal stiffness and direct performance. The thin profile section reduces drag, while the material properties help maintain structural integrity and rigidity. Stabs have a huge influence on performance. As you progress to smaller wing sizes, we recommend changing to a smaller stabilizer to be more manoeuvrable. Experienced riders will really feel the difference. A new tail can have a big impact on your style.
Features
Clean undisturbed flow
Flat
loose and fast
Easy breach recovery
Thinner profile
Higher aspect ratio
Less surface friction for better glide
Materials
Carbon Pre-preg
AXIS 460 V2 Pump Carbon Rear Wing
269,00 €*
Continuing the huge success of the AXIS 460 Carbon rear wing, was not an easy task. We kept the same chord, foil section, and wingspan of the original 460, but added a splash of turn down on the tips, similar to the Progressive rears.
This created a rear wing that is fast, stable, pumps unreal, and likes to turn with good carving performance. The perfect setup for all dock start, flat water pump, downwinding, wake, lightwind winging, and more.
If you don't have the AXIS 460 v2 rear wing in your bag of rear wings, you are certainly missing out. The AXIS 460 v2 carbon rear wing comes with its own AXIS cover, so your new AXIS wing is nicely protected.
We updated the graphics on this rear wing to show all the technical details you might be interested in (plus some):
Wingspan: 460mmMax Chord: 60mmTrue Area: 229.90cm2Aspect Ratio: 9.3Volume: 82.82cm3
NORTH Sonar S210 Stabilizer 2022
189,00 €*
Exceptional glide. Our new thinner profile and higher aspect ratio carbon stabilizers offer reduced resistance and a more efficient outline. The S270 is your go-to for all round kite, wing and surf performance, offering optimal balance, speed, efficiency and control. Pair the S210 with a smaller front wing for high-speed performance and a more agile feel. Pair the S320 with a larger front wing for early planing, greater balance and stability.
Features
Clean undisturbed flow
Easy breach recovery
Thinner profile
Higher aspect ratio
More efficient outline shape
Less surface friction for better glide
Materials
Carbon Pre-preg
SABFOIL S380/PF - Gullwing 380 Pro Finish I Hydrofoil Stabilizer
220,00 €*
Sabfoil Gullwing 380 Pro Finish | Hydrofoil Stabilizer
MAIN SPECS
Surface: 180 cm2
AR: 8,10
Wingspan: 380 mm
Chord: 60 mm
Range
Gullwing
Stabilizer-Fuselage Connection
Standard
This fast and versatile stabilizer is ideal for all those who want to increase the control and stability of their hydrofoil. The gullwing shape guarantees good directionality while riding without sacrificing maneuverability when needed.
The S380/PF is delivered with SAB Pro Finish, and thus hand sanded to achieve a matte surface with 0-thickness graphics, for an elegant Made in Italy product with maximum performance.
F-ONE Stab C220 Surf Foil Backwing 2023
180,00 €*
Fast and agile, the C220 SURF stabilizer provides a fantastic glide and a lot of freedom when riding.
Fantastic glide
Complete turning freedom
Constant balance for perfect control
Easy to turn and roll from rail to rail, it is a perfect fit for all the carving lovers who will enjoy its maneuverability. Designed with a high aspect ratio and thin profile, the C220 SURF stabilizer provides a friction-free feel when riding and allows for nice accelerations. Constant balance (front/back) is maintained at all speeds, which always means more control. This stab fits well with the MIRAGE CARBON front wings.
Built in pre-preg Carbon and designed to be securely mounted on F-ONE fuselages, its profile and angle of incidence were tuned to achieve a very intuitive balance.
Ref. 77207-0307
Recommended Plane:
DUOTONE Back Wing Aero Stabilizer C 2024
De
209,00 €*
Control
Unsere Stabilizer C haben sich in den letzten Jahren in Kombination mit sämtlichen Front Wings bestens bewährt. Sie sind das, was man als "traditionell" bezeichnen würde mit einer mittleren Aspect Ratio, flach in der Mitte und ein subtiles Winglet zu den Wing Tips hin.
Ein gut getestetes und bewährtes Design, das hervorragend mit unseren Aero Free SLS und Aero Lift SLS Front Wings zusammenpasst.
Die C-Serie steht für Kontrolle. Bei ihnen geht es darum, den Fahrer auf seiner Flugbahn zu unterstützen und dem Foil Kontrolleigenschaften zu verleihen, ohne den Spaßfaktor einzuschränken.
Obwohl sie einen stabilen Flug gewährleisten, sind sie perfekt für sanfte Turns auf der Welle.
Mit Hilfe der brandneuen dünnen Shims kannst du den Anstellwinkel deines Stabilizers in Schritten von +/- 0,3 Grad anpassen, passend zu deinem Fahrstil oder den aktuellen Bedingungen.
CABRINHA Fusion V-Series Tail Stabilizers 2023
De
202,00 €*
FUSION V-SERIES TAIL STABILIZERS
HIGH ASPECT
SIZES: 180 / 230 / 285
One of the biggest effects on hydrofoil performance comes from the stabilizers. In a sport that is so diverse in its attributes and styles of riding, you need to have the right product to help you get the maximum performance from your system. Introducing the new V-Series Stabilisers. V represents versatility, and through the modular Fusion system, you are able to custom tailor your ride. Add a V-Series Stabiliser to any of the Cabrinha Fusion foils and get ready for the next step in performance & usability.
Features:
Optimal efficiency and maneuverability
Flat center, to downward tips, for perfect balance between locked-in feel and agility
Single molded components for minimal drag
Full prepreg carbon construction
PMI core for superior strength to weight ratio
180 cm², WS-340, AR-6.42
230 cm², WS-400, AR-6.96
285 cm², WS-450, AR-7.11
Set Includes:
Stabilizer, wing covers, 2pcs m6 ss316 torx Ti coated screws, {(ear fuselage not included)
NORTH Sonar S270 Stabilizer 2022
199,00 €*
Exceptional glide. Our new thinner profile and higher aspect ratio carbon stabilizers offer reduced resistance and a more efficient outline. The S270 is your go-to for all round kite, wing and surf performance, offering optimal balance, speed, efficiency and control. Pair the S210 with a smaller front wing for high-speed performance and a more agile feel. Pair the S320 with a larger front wing for early planing, greater balance and stability.
Features
Clean undisturbed flow
Easy breach recovery
Thinner profile
Higher aspect ratio
More efficient outline shape
Less surface friction for better glide
Materials
Carbon Pre-preg
AXIS 350 Progressive Carbon Rear Wing
239,00 €*
The AXIS Progressive Rear Wings are perfectly paired with our HPS, ART, BSC and PNG wings. Mostly flat but with a very subtle downturn, these wings combine excellent speed with sensational turning.
Who are the AXIS Progressive rear wings for?The AXIS Progressive rear wings are all round wings for intermediate and advanced riders paired with higher performance front wings such as HPS, ART, PNG and BSC front wings.
You notice the difference in your first carve or gybe.
Why did we design the AXIS Progressive rear wings?We got super hooked on the locked in, fast, stable feel of the AXIS Speed 380/60 and 420/60 rear wings, and still are for flat water blasting and racing for winging and big, fast waves for foil surfing. But we had a feeling we still had more to give our riders in the turning department. After several iterations and tweaks, the new Progressive rears have delivered it in spades.Medium aspect, with a thin foil section and subtle turned down tips, this new design rolls into the turn beautifully, feels fluid and loose, and also grips through the carve and transitions back out the other side with predictable control and positive acceleration. Even intermediate foilers will notice the difference straight away. It’s super well-behaved in rough winging conditions (just set and forget) and with the thin foil section, it’s still rewardingly quick. The Progressive rear wings will feel like a natural extension of your feet.Riders are finding the Progressive rears pair beautifully with our AXIS ART and AXIS HPS high aspect front wings, and they’ll work very well with any foil for riders looking to improve their turns and carves. As always, size your Progressive rear wing to your experience and front wing size. (larger sizes for less experienced riders and larger front wing pairings)
We obsess over rear wings, almost to the point that it’s a problem. We’ve tried to get professional help but the prototypes just keep getting churned out by our design team on a weekly basis, and we can’t help but test, analyze, pontificate, redesign – and on and on it goes.
You may be thinking – why do rear wings matter? Aren’t they just stabilizers to balance the front wing? Well that’s what many thought too – in the very early days. We know that your rear wing can change your life. Okay that’s not quite true, but it will significantly affect the ride characteristics of your whole foil set up.
Try the AXIS Progressive rear wings and you will immediately know what we are talking about.
CABRINHA X-Series Rear Stabilizer 2022
131,00 €*
FUSION X TAIL STABILISER
HIGH ASPECT FOIL
XS220 XS300
DESIGN PROFILE
Swept LE, Straight TE, Lean profile, minimal anhedral with downturned tips
RIDER PROFIL
ultra-versatile wing set for all round water use
WING FEATURES
Optimal efficiency & lift for stable ride
Flat center, to downward tips, for perfect balance between locked-in feel and agility
Recessed design for minimal drag
Full prepreg carbon construction
EPS core for superior strength to weight ratio
Includes: Stabilizer, wing covers, 2pcs m6 ss316 torx Ti coated screws
The best part of the last 5 years has been the rise in hybrid development and crossover technology amongst sports. Nowhere is this more evident than in foil boarding. The hydrofoil has become the common denominator in all of the surf and wind sports today.
Therefore, it reasons that its important to have a hydro wing-set capable of crossing between sporting genres with flawless performance and capability. Enter the X Series™ wings from Cabrinha. The design of the X Series™ recognizes and exploits the most important features needed in all hydrofoiling genres. Lift, efficiency and control are the three pillars that drive the X Series’ high performance and buttery smooth ride.
Through a combination of outlines and wing profiles the X series delivers a smooth lift and stable flight with precise turning and control.
The X Series’ efficiency is enhanced by our all new Cab Fusion mast and fuselage ecosystem. The Cab Fusion is a redesign from the bottom up to remove any unwanted ‘play’ in the system while streaming the connection between the wings and the fuselage. The resulting increase in stiffness and reduction in drag puts the X Series wings into an all new class of hydrofoils.
SABFOIL REVERSE 395 PRO FINISH | HYDROFOIL STABILIZER
178,00 €*
Sabfoil Reverse 395 Pro Finish | Hydrofoil StabilizerMAIN SPECSSurface: 198 cm2AR: 8,08Wingspan: 400 mmChord: 64,96 mmSTABILITYMANEUVERABILITYSPEEDRangeReverseStabilizer-Fuselage ConnectionStandardRecommended with front wings600 - 1400 cm2Thanks to the slim profile and the accentuated reverse dihedral angle, this stabilizer is designed for those looking for excellent performance in terms of speed and directionality. The design also provides great maneuverability and makes it ideal for carving.The S395/PF is hand sanded to achieve a matte surface with 0-thickness graphics, the SAB Pro Finish, for an elegant Made in Italy product with maximum performance.
SABFOIL REVERSE 355 PRO FINISH | HYDROFOIL STABILIZER
178,00 €*
Sabfoil Reverse 355 Pro Finish | Hydrofoil StabilizerMAIN SPECSSurface: 160 cm2AR: 8,08Wingspan: 360 mmChord: 58,48 mmSTABILITYMANEUVERABILITYSPEEDRangeReverseStabilizer-Fuselage ConnectionStandardRecommended with front wings500 - 1100 cm2Thanks to the slim profile and the accentuated reverse dihedral angle, this stabilizer is designed for those looking for excellent performance in terms of speed and directionality. The design also provides great maneuverability and makes it ideal for carving.The S355/PF is hand sanded to achieve a matte surface with 0-thickness graphics, the SAB Pro Finish, for an elegant Made in Italy product with maximum performance.
DUOTONE Back Wing Stabilizer PX 2025
De
139,00 €*
Our new PX stabiliser range replaces our previous Range of P Stabs.
The stabs look almost identical; the only thing we've changed is the twist in the profile, from the root chord to the tips.Although this might sound insignificant, our team actually found that this small tweak improved just about every aspect of the P stabs.
Better pitch control, more manoeuvrability and improved pumping.
The PX sizes come in a slightly smaller surface area than the P.
PX160 replaces P165
PX175 replaces P180
PX195 replaces P200
Expect a little less front foot pressure when changing from the P to the slightly smaller PX. The PX pairs perfectly with our new Carve 3.0 range but can also be used with any of our other front wings: Glide, Glide 2.0, Carve, Whizz, specially if you want to improve the general performance of your foil for high speed winging and kitefoiling or when you are tackling bigger and faster waves.
SABFOIL Stabilizer 483 316 cm2 - AR 7,6 022
248,00 €*
The S483 can be used with any wave wing in our collection and will allow you to shorten the turn radius while maintaining a high entry speed and releasing energy during pumping.
STABILITY
MANEUVERABILITY
TOP SPEED
PRESSURE
EASE OF USE
ALL-ROUND
This stabilizer was created to give freedom and speed to our big front wings.
The S483 can be used with any wave wing in our collection. The inverted tip design will allow you to shorten the turning radius compared to the S450 stabilizer, maintaining a high entry speed and releasing energy during pumping.
AXIS SKINNY 365/55 Carbon Rearwing
285,00 €*
The development of the much faster-running ARTPRO wings prompted us to begin experimenting with reduced chord rear stabilisers to maximise this newfound speed advantage. With minimal span changes (just 7mm between them) and drastic chord reduction down to 55, 50, 45, 40 and 35mm, we found positive gains in speed, control, balance and feel. The Skinnies have inherited many of the same characterises that make our Progressive range so popular, like the precise feel and seamless turn initiation plus recovery. They are very low drag and free up speed and turning. Heavier riders and those less experienced will gravitate to the 55, 50 and 45 chord models, those who are lighter and or have greater experience might opt to reduce drag in the extreme and try the 40 or 35mm chord options.The Skinny rear wings inspire confidence by providing a more comfortable ride at speed, they reduce the normal buildup of front foot pressure that can be associated with high-speed foiling. They are a perfect match to ARTPRO foils, but keep in mind, your HPS, ART, PNG and even BSC, will equally benefit from the Skinny high-performance DNA.
AXIS Rear Wing 500mm Wingspan - Regular - Carbon 2021
269,00 €*
The AXIS Carbon 500 rear wing is the most stable of our rear wings. Ideal for the entry level and all round riders, the 500 will make your ride as stable as it gets. Suggested as an all round companion to our larger front wings (1020, 920).
You can combine the 500 rear wing with either the Standard, Short or ULTRA Short Red Fuselages for quicker turning and looser feel.
When you purchase the AXIS 500 carbon rear wing we include an AXIS padded cover with zipper, in heather gray, and AXIS branding, for safer setup, transportation and storage.
WINGSPAN: 500 mm / 19.69 in
CHORD: 90 mm / 3.54 in
ASPECT RATIO: 7.3
ACTUAL AREA : 360.77 cm² / 55.92 IN²
PROJECTED AREA: 342.55 cm² / 214.35 IN²
VOLUME: 130.8 cm³ / 8 IN³
AXIS Rear Wing 420mm High Aspect - Carbon 2021
259,00 €*
Imagine a shorter version of the AXIS 460 rear wing, with winglets.
That's exactly what the 420 carbon rear wing is.
Our fastest rear wing to date, at 420mm wingspan, 60mm chord, and 8.7 Aspect Ratio. FAST. And with the winglets it provides good turning and carving control.
If you are a performance Prone, SUP, Wing or Downwind foiler, looking for the fastest setup, then the 420 is just your wing.
When you purchase the AXIS 420mm carbon rear wing we include an AXIS padded cover with zipper, in heather gray, and AXIS branding, for safer setup, transportation and storage.
WINGSPAN: 420 mm / 16.54 in
CHORD: 60 mm / 2.36 in
ASPECT RATIO: 8.57
ACTUAL AREA : 212.63 cm² / 32.96 IN²
PROJECTED AREA: 205.76 cm² / 31.89 IN²
VOLUME: 76.95 cm³ / 4.70 IN³
AXIS Rear Wing 380mm High Aspect - Carbon 2021
239,00 €*
New for 2021, Narrow (only 60mm chord), High Aspect Ratio 7.99AR, flatter foil section, and 17mm winglets on the tips for more stability while hard carving. FAST and high performance.
It will take your ride to the next level.
Some of our pros love the 380 with the AXIS PNG 910 and the Crazyshort fuselage. It's also an amazing winging rear wing. No matter what your foiling sport is, the 380 will make it fast.Check out the video below from Huntington Beach, pumping and hunting for bumps on the above setup.
WINGSPAN: 380 mm / 14.96 in
CHORD: 60 mm / 2.36 in
ASPECT RATIO: 7.99
ACTUAL AREA : 193.04 cm² / 29.92 IN²
PROJECTED AREA: 180.62 cm² / 28 IN²
VOLUME: 69.11 cm³ / 4.22 IN³
AXIS 400 Freeride Carbon Rear Wing
239,00 €*
The AXIS 400 Carbon Rear Wing is the carving specialist. Even looser than the 440 rear wing, it's the most turny and performance oriented rear wing on our collection.
A must have with the 750 and 680 front wings, but also works miracles with the bigger wings, making the ride more playful and high performing. And when combined with the ULTRA Short Red fuselage then your ride gets looser than ever!
When you purchase the AXIS 400 carbon rear wing we include an AXIS padded cover with zipper, in heather gray, and AXIS branding, for safer setup, transportation and storage.
WINGSPAN: 400 mm / 15.75 in
CHORD: 90 mm / 3.54 in
ASPECT RATIO: 5.79
ACTUAL AREA : 291.18 cm² / 45.13 IN²
PROJECTED AREA: 276.54 cm² / 42.86 IN²
VOLUME: 175.35 cm³ / 10.70 IN³
Assembly
What screws to mount wing to the fuselage:
Rear Wing
Front Screw
Rear Screw
500mm x 90mm
M6 x 25mm
M6 x 25mm
440mm x 90mm
M6 x 25mm
M6 x 25mm
400mm x 90mm
M6 x 25mm
M6 x 25mm
460mm x 60mm
M6 x 22mm
M6 x 22mm
400mm x 60mm
M6 x 22mm
M6 x 22mm
420mm x 60mm
M6 x 22mm
M6 x 22mm
380mm x 60mm
M6 x 22mm
M6 x 22mm
390mm x 80mm
M6 x 25mm
M6 x 25mm
370mm x 80mm
M6 x 25mm
M6 x 25mm
340mm x 80mm
M6 x 25mm
M6 x 25mm
500mm x 90mm
M6 x 25mm
M6 x 25mm
AXIS 375 Progressive Carbon Rear Wing
239,00 €*
The AXIS Progressive Rear Wings are perfectly paired with our HPS, ART, BSC and PNG wings. Mostly flat but with a very subtle downturn, these wings combine excellent speed with sensational turning.
Who are the AXIS Progressive rear wings for?The AXIS Progressive rear wings are all round wings for intermediate and advanced riders paired with higher performance front wings such as HPS, ART, PNG and BSC front wings.
You notice the difference in your first carve or gybe.
Why did we design the AXIS Progressive rear wings?We got super hooked on the locked in, fast, stable feel of the AXIS Speed 380/60 and 420/60 rear wings, and still are for flat water blasting and racing for winging and big, fast waves for foil surfing. But we had a feeling we still had more to give our riders in the turning department. After several iterations and tweaks, the new Progressive rears have delivered it in spades.Medium aspect, with a thin foil section and subtle turned down tips, this new design rolls into the turn beautifully, feels fluid and loose, and also grips through the carve and transitions back out the other side with predictable control and positive acceleration. Even intermediate foilers will notice the difference straight away. It’s super well-behaved in rough winging conditions (just set and forget) and with the thin foil section, it’s still rewardingly quick. The Progressive rear wings will feel like a natural extension of your feet.Riders are finding the Progressive rears pair beautifully with our AXIS ART and AXIS HPS high aspect front wings, and they’ll work very well with any foil for riders looking to improve their turns and carves. As always, size your Progressive rear wing to your experience and front wing size. (larger sizes for less experienced riders and larger front wing pairings)
We obsess over rear wings, almost to the point that it’s a problem. We’ve tried to get professional help but the prototypes just keep getting churned out by our design team on a weekly basis, and we can’t help but test, analyze, pontificate, redesign – and on and on it goes.
You may be thinking – why do rear wings matter? Aren’t they just stabilizers to balance the front wing? Well that’s what many thought too – in the very early days. We know that your rear wing can change your life. Okay that’s not quite true, but it will significantly affect the ride characteristics of your whole foil set up.
Try the AXIS Progressive rear wings and you will immediately know what we are talking about.
AXIS SKINNY 362/50 Carbon Rearwing
279,00 €*
The development of the much faster-running ARTPRO wings prompted us to begin experimenting with reduced chord rear stabilisers to maximise this newfound speed advantage. With minimal span changes (just 7mm between them) and drastic chord reduction down to 55, 50, 45, 40 and 35mm, we found positive gains in speed, control, balance and feel. The Skinnies have inherited many of the same characterises that make our Progressive range so popular, like the precise feel and seamless turn initiation plus recovery. They are very low drag and free up speed and turning. Heavier riders and those less experienced will gravitate to the 55, 50 and 45 chord models, those who are lighter and or have greater experience might opt to reduce drag in the extreme and try the 40 or 35mm chord options.The Skinny rear wings inspire confidence by providing a more comfortable ride at speed, they reduce the normal buildup of front foot pressure that can be associated with high-speed foiling. They are a perfect match to ARTPRO foils, but keep in mind, your HPS, ART, PNG and even BSC, will equally benefit from the Skinny high-performance DNA.
