Produktinformationen "NORTH MODE PRO Wing 2027"

High-Speed Performance Freeride

For riders demanding powerful freeride performance with greater speed, explosive boost and hangtime. The stiff, lightweight N-Weave45 airframe and Matrix canopy deliver efficient power and high-end stability.

For 2027, the strut shape, panel layout and wingtip seam technology have been refined, while the stiffer XL-T Joint and UDi Carbon-reinforced leading edge provide an even faster, more direct response.

Features & Technologies

UDi Carbon-reinforced Leading Edge: Increases stiffness and responsiveness while reducing deflection.
Matrix high-load N-HTRS Canopy: Stretch-resistant material for torsional strength, structural integrity and increased wind range.
Refined True Form Profile: Provides fast acceleration and sustained speed.
Flatter dihedral: Generates greater lift, upwind performance and stability at speed.
Ergonomic Strut Geometry: Creates a comfortable riding position and reduces arm fatigue and elbow strain.
ShiftLock Modular Mounting: Allows custom positioning of compatible carbon handles, J-Handle or boom.
Connected Hyperflow Dual-Inflation: Independent LE and strut pressure with inflation and deflation from one point.
Compact outline and rounded wingtips: Reduce tip strikes.
Wingtip Seam Technology: Protects against abrasion.
Recycled polyester wing bag: Expands to fit a ShiftLock Boom.

Product Details

Discipline	High-Speed Performance Freeride
Airframe	N-Weave45
Canopy	Matrix
Color	White
Product Code	85014.270006

Size & Performance Guide

Recommended wing size depends on rider size, ability and foil setup.

Wing Size	Wingspan	Pressure	Wind Range	Ideal Rider Weight
3.5 m	2.62 m	10 PSI	18–36 knots	<40 kg
4.2 m	2.83 m	9 PSI	16–33 knots	<50 kg
4.8 m	3.05 m	9 PSI	13–31 knots	<60 kg
5.5 m	3.15 m	8 PSI	9–24 knots	<70 kg
6.5 m	3.26 m	7 PSI	7–21 knots	<80 kg

Recommended ShiftLock Setup

ShiftLock Carbon handles and booms are sold separately.

Wing Size	Front Handle	Rear Handle	Boom	Wrist Leash
3.5 m	400 mm	400 mm	950 mm	M, 1800 mm
4.2 m	400 mm	400 mm	1100 mm	M, 1800 mm
4.8 m	400 mm	400 mm	1100 mm	M, 1800 mm
5.5 m	500 mm	400 mm	1100 mm	M, 1800 mm
6.5 m	500 mm	400 mm	1100 mm	L, 2400 mm

The 3.5 m size is compatible with both 1100 mm and 950 mm booms. The Action Camera Mount can only be combined with the 950 mm boom.

Item Includes

Wing
Wrist Wing Leash
Sonar T40 Tool
Wing Bag
Compression Strap
Repair Kit
Sand Bag
