1750 DESCRIPTION The Universal ALU foil set is the tool to enter the exhilarating foil dimension. You can switch the use of this phenomenal set from Wing, to Surf, to SUP, to Kite foiling without the need to change your hydrofoil! This hydrofoil is capable of speeding up the learning process as you never thought was possible.The new Universal SW alu is available in two versions with 75 cm or 85 cm aluminum mast. The 75 cm mast is recommended to better keep control during your first flights, while the 85 cm mast is preferable once you progress and are able to ride for longer distances.The new Universal SW 1750 full carbon front wing is the engine of the whole system. Its generous wingspan and thicker profile will create the right lift to start foiling at low board speed and help to keep stability and control once you are flying! Your jibes and tacks are going to be so easy and you will learn how to pump on flat water or ground small swell. The rear wing is 52 cm wide and has a negative dihedral angle of -26°. This angled wing design improves the “pumping” and carving ability of the foil. This hydrofoil is capable of speeding up the learning process as you never thought was possible! Recommended for novice riders, the ideal hydrofoil for schools. UNIVERSAL SW ALU 1750 – 75 DELIVERED WITH: UNIVERSAL ALU MAST  75 WITH PLATE and EVA COVER Y26 UNIVERSAL FULL CARBON FRONT WING 98/1750 with PADDED COVER Y26 UNIVERSAL FULL CARBON REAR WING 52/373 Y26 with PADDED COVER Y26 FUSELAGE 76 with EVA COVER Y26 M8 TORX SCREWS & KEY SET M6 TELESCOPE SCREWS & KEY SET UNIVERSAL SW ALU 1750 – 85 DELIVERED WITH: UNIVERSAL ALU MAST  85 WITH PLATE and EVA COVER Y26 UNIVERSAL FULL CARBON FRONT WING 98/1750 with PADDED COVER Y26 UNIVERSAL FULL CARBON REAR WING 52/373 Y26 with PADDED COVER Y26 FUSELAGE 76 with EVA COVER Y26 M8 TORX SCREWS & KEY SET M6 TELESCOPE SCREWS & KEY SET DESCRIPTION The Universal ALU foil set is the tool to enter the exhilarating foil dimension. You can switch the use of this phenomenal set from Wing, to Surf, to SUP, to Kite foiling without the need to change your hydrofoil! This hydrofoil is capable of speeding up the learning process as you never thought was possible.The new Universal SW alu is available in two versions with 75 cm or 85 cm aluminum mast. The 75 cm mast is recommended to better keep control during your first flights, while the 85 cm mast is preferable once you progress and are able to ride for longer distances.The new Universal carbon front wing 2400 is your ticket to learn how to fly in literally no time and with the lightest wind. Its large and generous dimensions with extra thick profile will let you take off with ease and learn your first jibes and tacks. The rear wing is 52 cm wide and has a negative dihedral to improve the “pumping” and carving ability of the foil. Recommended for novice heavy weight riders, the ideal hydrofoil for schools. UNIVERSAL SW ALU 2400 – 75 DELIVERED WITH: UNIVERSAL ALU MAST  75 WITH PLATE and EVA COVER Y26 UNIVERSAL FULL CARBON FRONT WING 110/2400 with PADDED COVER Y26 UNIVERSAL FULL CARBON REAR WING 52/373 Y26 with PADDED COVER Y26 FUSELAGE 76 with EVA COVER Y26 M8 TORX SCREWS & KEY SET M6 TELESCOPE SCREWS & KEY SET   UNIVERSAL SW ALU 2400 – 85 DELIVERED WITH: UNIVERSAL ALU MAST  85 WITH PLATE and EVA COVER Y26 UNIVERSAL FULL CARBON FRONT WING 110/2400 with PADDED COVER Y26 UNIVERSAL FULL CARBON REAR WING 52/373 Y26 with PADDED COVER Y26 FUSELAGE 76 with EVA COVER Y26 M8 TORX SCREWS & KEY SET M6 TELESCOPE SCREWS & KEY SET

The new ION safety footstrap offers a adjustable emergency opening during crashes.

2022/23 Naish Jet Foil Series for maximum performance There are three versions: Jet Foil HA (High Aspect) Semi Complete Jet Foil MA (Medium Aspect) Semi complete Jet Foil Standard (Low Aspect) Semi Complete Here are the main differences between these models. High Aspect (HA) Foil: High aspect foils typically have longer wings with a narrower chord (width) and a higher aspect ratio (length to width ratio). These foils are known for providing greater efficiency and speed, making them suitable for advanced users and those looking for maximum performance. High aspect foils are often preferred for racing and advanced foiling maneuvers due to their reduced drag and improved lift-to-drag ratio. Medium Aspect (MA) Foil: Medium aspect foils strike a balance between the characteristics of high and low aspect foils. They are versatile and can cater to a wider range of riders, offering a good compromise between stability, speed, and maneuverability. Medium aspect foils are suitable for intermediate foilers who want a balance of performance and control. Low Aspect (LA) Foil: Low aspect foils typically have shorter wings with a wider chord, resulting in a lower aspect ratio. These foils are known for providing more stability and ease of use, making them suitable for beginners and those who prioritize comfort over maximum speed. Low aspect foils are often chosen for learning to foil and for cruising at lower speeds. When comparing the 2022 Naish Jet Foil HA, MA, and Standard models, you can expect the High Aspect to prioritize performance and speed, the Medium Aspect to offer a balance of features, and the Standard (Low Aspect) to focus on stability and ease of use. The high number (for example 1600) gives you the surface of the front wing in cm2. Scope of delivery:Jet front wing + EVA coverStabilizer Jet HA + EVA coverFuselageCarrying caseTorx screwdriver and required screws (5x 20 mm M6/4x 30 mm M6 + T Nuts)

3 Pieces / 3 Stück

Flat, loose and even faster, the new S178 Stabilizer is a high-speed upgrade to the Sonar Foil System for experienced riders. We recommend pairing the S178 with Front Wing size HA950, or smaller. The S178 has a higher aspect ratio than the S208. Features Top mounted for early breach recovery​ Carbon pre-preg construction​ Thin profile section for reduced drag​ Materials Pre-Preg Carbon

Versatile and progressive, the IC6 300 stabilizer is the perfect match for the IC6 950 and GRAVITY FCT front wings. Equipped with generous winglets, this stabilizer offers fantastic control with enough surface area that will help you feel fully confident in all situations. Versatile, intuitive, and predictable Large range of use Built with the IC6 technology, it is very durable and designed to be securely mounted on F-ONE fuselages. Its profile and angle of incidence were tuned to achieve a very intuitive balance which will help you maneuver your foil more easily. Ref. 77207-0301 Recommended Plane:

Flat, loose and fast, the new S208 Stabilizer is another high performance upgrade to the Sonar Foil System for experienced riders. The S208 has a higher aspect ratio than the S210, which means less drag, and the flatter rondure (front view) enables more manoeuvrability. As we’ve increased our front wing range, we’ve needed to match the lift force of the front wing with the stabilizer. While your front wing creates vertical lift, your stabilizer has a downward acting force, which prevents the front wing from nose-diving. A larger stabilizer translates into more front foot pressure, while a smaller stabilizer equals less front foot pressure. The North stabs are mounted on top of the fuselage, which helps them to avoid turbulence from the flow of the front wing, creating a smoother ride. This top mounting also gives the rider an early breach warning - the stab pierces the water surface first, giving you a better chance of recovery before your front wing gets too high. Like the Front Wings, all Sonar Stabilizers are pre-preg carbon construction, ensuring optimal stiffness and direct performance. The thin profile section reduces drag, while the material properties help maintain structural integrity and rigidity. Stabs have a huge influence on performance. As you progress to smaller wing sizes, we recommend changing to a smaller stabilizer to be more manoeuvrable. Experienced riders will really feel the difference. A new tail can have a big impact on your style.   Features Clean undisturbed flow Flat loose and fast Easy breach recovery Thinner profile Higher aspect ratio Less surface friction for better glide Materials Carbon Pre-preg

Q01K NOT INCLUDED (KRAKEN QUICK RELEASE) Kraken Mast Plate Kraken Modular System ALL-ROUND Connection SystemKraken Modular System The Kraken Mast Plate is one of the modular connection systems for masts, together with its tuttle counterpart (T03K). The strong point of this system is its modularity, as it is always possible to use your mast both with plate and with tuttle. This Plate has been designed for maximum lightness and strength. It has been milled directly in our factory starting from premium aluminum ingots and then it has been deeply anodized by certified partners. The Kraken Mast Plate also makes it possible to upgrade your set-up with the quick release system (Q01K), thanks to which you can assemble and disassemble your hydrofoil in a few seconds, without losing the configuration on the board.

FUSION ALLOY TOP PLATE MKII HIGH PERFORMANCE - DURABILITY SIZES: ONE SIZE The Fusion Alloy Top Plate is constructed from extruded aircraft grade aluminium that result in an incredibly rigid mast to board socket connection. It can be used with any Cab Fusion alloy mast. Features: Precision CNC machined aircraft grade, anodized 6061-T6 aluminium Incredible torsional stiffness

Wing / SUP / Prone // Beginner: 82/76-1750/250 /// Intermediate: 82/66-1500/250 Unser Favorit für alle Einsteiger der mittleren Gewichtsklassen zwischen 65 kg und 85 kg! Mit dem Quickmount Mast verbringst du weniger Zeit beim Schrauben und mehr Zeit auf dem Foil. Das gutmütige und gleichzeitig aufregend zu fahrende Aero Free 1750 wirst du von den ersten Versuchen bis zum gehobenen Fahrlevel lieben.

Insane response. Incredible performance. Our highest quality pre-preg carbon modular foil edition provides a stiffer, more direct feel and more immediate feedback. Engineered with exceptional stiffness for all disciplines, the CF Edition is made from lightweight and durable carbon pre-preg components and has a reduced swing weight for an agile, dynamic and direct feel, and great pumpability. The refined one-piece mast design is tapered for optimal load transfer and lower surface friction, and features our unique GeoLock system. The longer CF85 mast increases overall ride performance in choppy conditions. The CF72 mast is ideal for shallower waters, prone surf foiling and towing. For 2022 we’ve added stability, performance and efficiency with the 700mm Carbon Pre-Preg Fuselage and new S270 Carbon Pre-preg Stabilizer.    Carbon CF72 or CF85 Mast with cover, C700 Fuselage, S270 Stabilizer with cover, Tool Kit, Sonar Fuselage Screw Pack B (M8x35 Screws, M8 Flat Washers), Sonar Stabilizer Screw Pack C (M8x16mm)*, Sonar Travel Bag   Features Sonar CF85 or CF72 Mast GeoLock Load Bearing Connection NEW S270 Carbon Stabilizer with easy breach recovery Industry-standard 165x90mm bolt pattern C700 Carbon Fuselage Modular foil system Supplied with Sonar CF Edition Travel Bag Front Wings Sold Separately Foil to board mounting screws sold separately

Exceptional glide. Our new thinner profile and higher aspect ratio carbon stabilizers offer reduced resistance and a more efficient outline. The S270 is your go-to for all round kite, wing and surf performance, offering optimal balance, speed, efficiency and control. Pair the S210 with a smaller front wing for high-speed performance and a more agile feel. Pair the S320 with a larger front wing for early planing, greater balance and stability.   Features Clean undisturbed flow Easy breach recovery Thinner profile Higher aspect ratio More efficient outline shape Less surface friction for better glide Materials Carbon Pre-preg

Sabfoil Gullwing 380 Pro Finish | Hydrofoil Stabilizer MAIN SPECS Surface: 180 cm2 AR: 8,10 Wingspan: 380 mm Chord: 60 mm Range Gullwing Stabilizer-Fuselage Connection Standard This fast and versatile stabilizer is ideal for all those who want to increase the control and stability of their hydrofoil. The gullwing shape guarantees good directionality while riding without sacrificing maneuverability when needed.   The S380/PF is delivered with SAB Pro Finish, and thus hand sanded to achieve a matte surface with 0-thickness graphics, for an elegant Made in Italy product with maximum performance.

JET HA SEMI-COMPLETE Expert Performance Foil Surfing/Downwind Foiling/Wing-Surfing Designed for advanced and semi-advanced foilers looking to push their performance levels in surf, SUP, Wing-surfer, and downwind foiling. These wings feature high aspect ratio planforms and proprietary thin section profiles — the result is maximum glide, excellent pumping, and improved top speed while still maintaining the excellent turning and control that defines the Jet range. To complement the high-end performance of these new wings, the complete foils feature a new high aspect stabilizer that emphasizes pumping ability and glide. Designed with a thinner profile and higher aspect ratio, they support the higher speed of the HA front wings while giving excellent response to rider input. Learn More About the New Fuselage & Mast System HERE SET INCLUDES Jet HA Front Wing  Stabilizer HA   64 cm Fuselage 5x 20 mm M6//4x 30 mm M6 + T Nuts EVA Wing Covers Carry Case  CONSTRUCTION FEATURES 100% Pre-preg 3K High Gloss Carbon Fiber Front Wing and Stabilizer CNC Precision Cut Lightweight Aluminum Fuselage with Corrosion Resistant Stainless Steel M6 Helicoils for the Front Wing and Stabilizer Connection Stainless Steel M6 Torx T30 Hardware for all Screwed Connections Front WingAspect RatioWingspanProjected Surface AreaStabilizerFuselage Jet HA 1040 7.9 34.3"/87 cm 161.2 in²/1040 cm² Jet HA 220 64 cm Jet HA 1240 7.2 37.2"/94.5 cm 192.2 in²/1240 cm² Jet HA 280 64 cm Jet HA 1400 6.9 38.6"/98 cm 217 in²/1400 cm² Jet HA 280 64 cm Jet HA 1800 5.6 39.4"/100 cm 279 in²/1800 cm² Jet HA 310 64 cm Jet HA 2140 5.4 42.3"/107.5 cm 331.7 in²/2140 cm² Jet HA 310 64 cm

FUSION CARBON HOLLOW MAST HIGH PERFORMANCE - LIGHT WEIGHT SIZES: 74 / 84 / 94 CM The all-new Hollow Mast system is yet another example of the state of the art foil program from Cab Design Works. It nods to the critical & complete design approach of the team to view every foil component individually with a view to improve stiffness across the entire platform. It implements a bladder molded construction with strategic layering of carbon as far to the outside as possible. This culminates in our stiffest ever mast to front wing connection. This reduction in flex eliminates any lag in the turn and transfers energy while pumping seamlessly through to the front wing.   Features:   Optimized airfoil for low drag to stiffness ratio TE scallop for improved turning and efficiency Integrated high modulus mounting plate Bladder molded, hollow mast construction for superior skin compression, providing ultimate rigidity Premium high modulus prepreg carbon fiber construction Barrel Nut compatible(x-series MkII and H-series MKII) Tapered Fit Mast Guide:

GRAVITY FCT 2200 COMPLETE FOIL WITH MAST The foils of the Gravity line are designed to provide a solid lift with a smooth take-off and great carving potential. Right in the line of its best-selling carbon sibling, this new Gravity is the ideal foil to get started and progress in wing-foiling and surf-foiling.   Smooth take-off Stability and lift Easy to turn  Area: 2195 cm²Span: 110 cmAspect Ratio: 5.5Weight: 2 kg (wing only)Alu Fuselage: 74 Surf

Exceptional glide. Our new thinner profile and higher aspect ratio carbon stabilizers offer reduced resistance and a more efficient outline. The S270 is your go-to for all round kite, wing and surf performance, offering optimal balance, speed, efficiency and control. Pair the S210 with a smaller front wing for high-speed performance and a more agile feel. Pair the S320 with a larger front wing for early planing, greater balance and stability.   Features Clean undisturbed flow Easy breach recovery Thinner profile Higher aspect ratio More efficient outline shape Less surface friction for better glide Materials Carbon Pre-preg

MAX EFFICIENCY + PERFORMANCE The newly developed Jet High Aspect foils have been engineered for maximum efficiency and performance. They feature an increased leading edge area allowing for narrower foil sections, resulting in improved glide and stability. The strategically designed wing tips offer exceptional speed, pumping efficiency, and turning ability. The combination of these elements results in a maneuverability that has never been seen before with HA foils. The slight rake angle reduces drag while providing more control and improved lift during turns. This new design also allows the foil to breach the surface without interrupting laminar flow. The new features on the Jet HA provide an optimized experience that allows riders to foil with ease, making it ideal for all types of riders regardless of skill level. The Jet HA offers an optimal balance between stabilization and performance that ensures smooth handling on any type of wave or swell.

A true masterpiece of composite craftmanship and design, the F-ONE HM CARBON MAST 14 will transform your foiling experience. Slice through the water and enjoy the purest glide with its ultra-thin profile, full Monobloc structure and High Modulus Carbon construction.  Ultra-thin 14mm profile Full Monobloc construction High Modulus Carbon layup  High performance Increased rigidity The HM Carbon Mast 14mm thick features both a new integrated top plate and TITAN mast foot at the bottom. Associated with the profile, this full Monobloc construction brings incredible rigidity and helps reduce drag to a minimum, meaning easier starts, immense glide, higher speeds and the utmost connection between the foil and the board.  The mast is in one piece and built in carbon pre-preg, all molded and cured in one shot. Our SPINE internal structure ensures the best rigidity and control while riding. The added High Modulus Carbon (M40J) fiber layup follows F-ONE’s special recipe to optimize both the bending and torsional stiffness, allowing you to fully stay in control and comfortable in all situations and at high speeds. The layers of carbon fibers have been carefully distributed at 0° lengthwise to optimize stiffness in bending and at about 45° to optimize stiffness in torsion. Finally, this layup has been finely tuned and optimized for each mast length to offer the best performance in each sport.  With a size range going from 80cm, 85cm, 95cm to 105cm, this mast is ready for all disciplines — surf, wing, kite — and will particularly excel in downwind and where glide is your top priority. The 80cm is our newest size and was developed specifically for surf foiling, offering better pumping abilities and reducing undesirable breaching of the wingtips on the waves.  This mast can be connected to virtually all boards on the market featuring the Twin-Tracks system and can receive all the wings and fuselage that feature the TITAN connection slot.  Let it glide, further, with the F-ONE HM Carbon Mast 14, a superior piece of gear that raises the bar in terms of performance and control, delivering superior and flawless behavior on the water.

The MA1350 Front Wing is a mid-aspect ratio wing ideal for all rider weights. Easily generates lift without pumping. This performance wing is fast turning, with early planing ability for lighter wind conditions or heavier riders. Suitable for Kite, Wing, Surf and Tow Foiling. Features Higher speed top end performance Extremely fast and responsive turning radius Incredibly efficient Insane glide and pumpability Materials Carbon Pre-preg

HA 1125... TAKING PERFORMANCE, SPEED AND GLIDE TO THE NEXT LEVEL! Performance, speed and glide have been taken to the next level with the High Aspect 1125. It was developed with key design input from Pete Burling, helmsman of Team New Zealand’s Americas Cup yacht (Current AC holders) and tested by legendary sailor, Jimmy Spithill. Pete, Jimmy and Armie became friends as foiling united their search and passion for ultimate performance and glide on downwind runs. The mad scientist and these high-performance sailing gurus have collaborated to create something the likes of which has not seen before outside the Americas Cup! At 9.8:1 it’s a true High Aspect ratio foil wing that sets the standard for glide performance, while retaining enough handling that it can be turned easily, making for an exhilarating ride. Downwind aficionados requiring max glide performance will want to get their hands on this wing simply because it is next level! In small surf on an 85cm mast or longer, the HA1125 can be ridden to good effect, the turning radius is surprisingly good for is high aspect ratio. The sleek, inflected tips help prevent ventilation even if a tip breaches. It’s next level pump and glide make it easy to double dip! For experienced wingers there is no comparison. It makes tacking fun and easy as the glide gives you so much time to complete maneuvers like 360’s. Combine this with amazing upwind angles and outrageous downwind glide, as well as freakish light wind performance and the riding it just never stops! Construction Construction is based around a high-density foam core, which is wrapped with 100% IM and High Modulus Carbon.  The main wings are shaped and refined for maximum stability and predictability at all speeds The foil sections have been carefully designed by one of the world’s foremost sport wing designers. DimensionsArea: 1125 cm2Wingspan: 1050 mmWeight: 955 gramsAspect Ratio: 9.8

Red Advance Fuselage (+40) If you're into pushing the envelope in Prone, SUP, Wake, Wing or Pump, these will blow your mind. Are you looking to push harder, carve tighter turns and want an even more connected feeling on the larger PNG and BSC front wings? Our new Red Advance fuselage is for you.In three different sizes you get tons of options to fine tune your setup. This design sees the mast position moved 40mm closer to the front foil, opening up entirely new options for performance.The regular Red fuselages are perfectly suited to the majority of riders across all disciplines. By no means are these new Red Advance fuselage intended to replace them. They just provide options for performance and a more connected feel when pushing the limits. As the mast position on the Red Advance Fuselage is moved closer to the front wing, the effective length of the fuselage behind the mast is now slightly increased (by 40mm). When choosing your Red Advance Fuselage, it’s advisable to possibly opt for a length shorter than you are currently using. If you’re currently using an Ultrashort, you might consider the Crazyshort instead.   The Red Advance fuselage is available in Short, Ultrashort and Crazyshort sizing. Compatible with all the front wings that use the red fuselage. Compared to the regular Red fuselage range, these 3 new little siblings provide a looser, smoother transition from side-to-side. The sensation our testers liken it to is similar to the sensation of moving fins forward in the tracks on a surfboard. Initiating turns becomes easier, which is great in the surf. In an effort to reduce the use of cardboard and excess packing material, all the Black and Red ADVANCE fuselages are shipping with the matching new fuselage protective covers. Better for your gear. Better for the environment.

FUSION ALLOY MAST MKII HIGH PERFORMANCE - DURABILITY SIZES: 40 / 65 / 75 / 85CM MAST The Fusion Alloy mast is constructed from extruded aircraft grade aluminum that result in an incredibly rigid & hydrodynamic structure. Helicoil inserts eliminate salt water corrosion around the screw connection points. It seamlessly integrates into all 9cm industry standard foil boxes.   Features: Choice of fixed top plate or FQR (Foil Quick Release) 3-screw connection for superior rigidity Aircraft grade extruded, anodized 6061-T6 aluminum Precision tapered fuse-to-mast connection for optimal rigidity Helicoil inserts minimizes corrosion and provides long lasting durability Mast Guide:

FUSION FQR HIGH PERFORMANCE - DURABILITY SIZES: ONE SIZE The Patent pending Cabrinha Foil Quick Release is an innovative new tool-less mast plate that allows you to detach your foil mast from the board in seconds. The tapered engagement provides a press fit that will ensure a solid connection without any movement. Gone are the days of trying to tetris pack your foil boards to and from the beach, simply pull the release lever and the mast detaches. The FQR release attaches to all industry standard 9cm foil board track. Features: Cam lever - Tool less operation Aircraft grade extruded, anodized 6061-T6 aluminium components Lightning fast attachment Universal 9cm mounting Safety key engagement tapered engagement Anti-line snag geometry - increased safety when kiting Precision calibration design
